Product Summary

The 022057038 is a 2.54mm Pitch KK Wire-to-Board Header.

Parametrics

022057038 absolute maximum ratings: (1)Current - Maximum per Contact: 4A; (2)Voltage - Maximum: 250V; (3)Temperature Range - Operating: -40℃ to +105℃.

Features

022057038 features: (1)Orientation: Right Angle; (2)PC Tail Length: 3.80mm; (3)PCB Locator: No; (4)PCB Retention: None; (5)Packaging Type: Bag; (6)Pitch - Mating Interface: 2.54mm; (7)Pitch - Termination Interface: 2.54mm; (8)Plating min - Mating: 5.080μm; (9)Plating min - Termination: 5.080μm.

Diagrams

022057038 block diagram
