Product Summary

The 1-770972-0 is a soft shell pin and socket connector.

Parametrics

1-770972-0 absolute maximum ratings: (1)UL Flammability Rating = UL 94V-0; (2)Voltage (VAC): 600V; (3)Current Rating (A): 9.5A.

Features

1-770972-0 features: (1)Connector; (2)Header; (3)Connector Style = Plug; (4)Contact Type = Pin; (5)Through Hole Contact Termination Type.

Diagrams

1-770972-0 block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
1-770972-0
1-770972-0
TE Connectivity / AMP
Headers & Wire Housings HEADER 12 POS R/A TIN DUAL ROW
Data Sheet
0-1: $1.89
1-25: $1.73
25-100: $1.57
100-500: $1.34
