Product Summary

The 4-1393240-5 is a General Purpose Relay. The applications of the 4-1393240-5 include Boiler control, timers, garage door control, POS automation, interface modules.

Parametrics

4-1393240-5 absolute maximum ratings: (1)Contact - Rated Current (A) = 16; (2)Coil - Resistance (Ω) = 360; (3)Coil - Rated Power, DC (mW) = 400; (4)Actuating System = DC; (5)Coil - Rated Power (W) = 0.40; (6)Input Voltage (VDC) = 12; (7)Insulation - Special Features = None; (8)Insulation - Initial Dielectric Between Contacts and Coil (V rms) = 5000; (9)Insulation - Tracking Index of Relay Base = PTI250; (10)Coil Rating = Sensitive; (11)Release/Reset Voltage (V) = 1.2.

Features

4-1393240-5 features: (1)1 pole 12A/16A, 1 form C (CO) or 1 form A (NO) contact; (2)DC or AC coil; (3)5kV/10mm coil-contact, reinforced insulation; (4)Ambient temperature 85℃ (DC coil); (5)WG version: product in accordance to IEC 60335-1; (6)Reflow version: for THR (Through-Hole Reflow) soldering process.

Diagrams

4-1393240-5 block diagram
