Product Summary

The 555051-1 is a Modular Coupler.

Parametrics

555051-1 absolute maximum ratings: (1)Current: 1 Ampere maximum; (2)Operating Temperature: -40 to 60℃; (3)Dielectric Withstanding Voltage: 1000 Vac (rms).

Features

555051-1 features: (1)Region = Asia, North America; (2)8 Positions; (3)Body Style = Right Angle; (4)Not Keyed; (5)Coupler Type = MJ/MJ.

Diagrams

5555003-1 circuit diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
555051-1
555051-1
TE Connectivity / AMP
Ethernet & Telecom Connectors 8 COUPLER R/A
Data Sheet
0-1: $3.25
1-25: $2.87
25-50: $2.63
50-100: $2.42
