Product Summary
The ALD112W is a 1 Form A Slim Power Relay.
Parametrics
Absolute maximum ratings: (1)Max. operating speed: 20 cpm (at rated load); (2)Initial insulation resistance*1: Min. 1,000 MΩ (at 500 V DC); (3)Initial*2 breakdown voltage: 750 Vrms for 1 min Between open contacts, 4,000 Vrms for 1 min at Between contact and; (4)coil; (5)Initial surge voltage between contact and coil*3: Min. 10,000 V; (6)Operate time*4 (at nominal voltage): Max. 10ms (at 20 ℃); (7)Release time (with diode)*4 (at nominal voltage): Max. 10ms (at 20 ℃); (8)Temperature rise (at 70 ℃): Max. 45 ℃ with nominal coil voltage and at 3 A contact carrying current (resistance method).
Features
Features: (1)Slim type: Width 7 mm; (2)Perfect for small load switching of home appliances; (3)Low operating power; (4)High shock resistance; (5)High insulation resistance; (6)UL/CSA, VDE, TUV approved.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 ALD112W |
Panasonic Electric Works |
General Purpose / Industrial Relays 1 Form A 3A 277VAC 3A 30VDC 12V |
Data Sheet |
|
|
||||||||||||
