Product Summary

The 1376348-1 is a 5mm Power Key Connector.

Parametrics

1376348-1 absolute maximum ratings: (1)Voltage Rating: 300VAC; (2)Current Rating: 7A; (3)Temperature Rating: -30℃ to 105℃; (4)Minimum Rating: 1mV, 1μA Minimum; (5)Applicable P.C.B: Thickness: 1.6 mm.

Features

1376348-1 features: (1)Grace Inertia Product Line; (2)Wire-to-Board, Wire-to-Board / Wire-to-Wire, Wire-to-Wire; (3)Contact; (4)Applies To Wire/Cable; (5)Wire/Cable Size = 20 - 24 AWG.

Diagrams

1376348-1 block diagram
