Product Summary

The 1-1649329-3 is a Power PCB Relay. The applications of it are Boiler control, timers, garage door control, POS automation, interface modules.

Parametrics

1-1649329-3 general specifications: (1)Contact arrangement: 2 form C (CO) or 2 form A (NO); (2)Rated voltage: 250VAC; (3)Max. switching voltage: 400VAC; (4)Rated current: 8A, UL: 10A; (5)Limiting continuous current: 8A, UL: 10A; (6)Limiting making current, max. 4s, duty factor 10%: 15A; (7)Breaking capacity: max. 2000VA.

Features

1-1649329-3 features: (1)2 pole 8A, 2 form C (CO) or 2 form A (NO) contacts; (2)DC or AC coil; (3)5kV/10mm coil-contact, reinforced insulation; (4)Ambient temperature up to 85℃; (5)WG version: product in accordance to IEC60335-1; (6)Reflow version: for THR (Through-Hole Reflow) soldering process.

Diagrams

1-1649329-3 circuit diagram
