Product Summary

The 182649-1 is a CPC (Circular Plastic) and Circular Metal-Shell Connector.

Parametrics

182649-1 absolute maximmum ratings: (1)Connector Type = Housing; (2)Mount = Free Hanging; (3)Mount Angle = Straight; (4)Shell Size = 17; (5)Shell Type = All Plastic; (6)Product Series = Series 1; (7)Thread Size = 15/16-20 UNEF-2A; (8)Sealed = No.

Features

182649-1 features: (1)Housing; (2)Connector Style = Plug; (3)14 Positions; (4)14 Signal Positions; (5)0 Power Positions.

Diagrams

182649-1 block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
182649-1
182649-1
TE Connectivity / AMP
Standard Circular Connectors 17-14 PLUG
Data Sheet
0-1: $2.73
1-25: $2.40
25-50: $2.29
50-100: $2.18
