Product Summary

The 520935-1 is a Positive Lock Connector.

Parametrics

520935-1 absolute maximum ratings: (1)Product Type = Connector; (2)Mating Area Interface Dimensions (mm [in]) = 6.35 [.250]; (3)Color = Natural; (4)Material = Nylon; (5)Keyed = No; (6)Body Shape = Style Z.

Features

520935-1 features: (1)Connector; (2)Not Preloaded; (3)Connector Style = Plug; (4)Accepts Contact Gender = Receptacle; (5)Mating Area Interface Dimensions = 6.35 mm.

Diagrams

520935-1 block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
520935-1
520935-1
TE Connectivity / AMP
Headers & Wire Housings .25 POS LOCK
Data Sheet
0-1: $0.16
1-10: $0.14
10-100: $0.13
100-500: $0.11
