Product Summary

The 794189-1 is an AMP soft shell pin and socket connector.

Parametrics

794189-1 absolute maximum ratings: (1)Voltage Rating: 600 VAC/DC; (2)Current Rating: 3 A; (3)Overall Resistance: 10 mΩ max. (initial); 20 mΩ max. (final); (4)Insulation Resistance: 500 Ω (500 VDC); (5)Dielectric Withstanding Voltage: 1,100 VAC, one minute; (6)Contact Resistance: 20 mΩ max; (7)Operating Temperature: -30℃ to +105℃.

Features

794189-1 features: (1)Connector; (2)Housing; (3)Connector Style = Receptacle; (4)Mini-Universal MATE-N-LOK 2; (5)4.14 mm Centerline.

Diagrams

794189-1 block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
794189-1
794189-1
TE Connectivity / AMP
Pin & Socket Connectors 4P MINI PLUG HSG
Data Sheet
0-1: $0.40
1-25: $0.38
25-100: $0.28
100-500: $0.25
